Micom P631 - Page 399

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LOGIC: Sig.assig. outp. 28
044 054
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig. outp. 29
044 056
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig. outp. 30
044 058
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig. outp. 31
044 060
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig. outp. 32
044 062
061 000: MAIN: Without function
[spacer]
These settings assign the function of a binary input signal to the output of the
logic equation.
[spacer]
LOGIC: Sig.assig.outp. 1(t)
044 001
061 000: MAIN: Without function Fig. 3-148, (p. 3-179)
[spacer]
LOGIC: Sig.assig.outp. 2(t)
044 003
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp. 3(t)
044 005
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp. 4(t)
044 007
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp. 5(t)
044 009
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp. 6(t)
044 011
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp. 7(t)
044 013
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp. 8(t)
044 015
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp. 9(t)
044 017
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp.10(t)
044 019
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp.11(t)
044 021
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp.12(t)
044 023
061 000: MAIN: Without function
[spacer]
LOGIC: Sig.assig.outp.13(t)
044 025
061 000: MAIN: Without function
