Parameter Address
Default Min Max Unit Logic Diagram
“Logical”
communication
interface 1
COMM1: Command block. EXT
003 173
0: No
[spacer]
COMM1: Sig./meas. block EXT
037 074
0: No
[spacer]
COMM1: Command blocking
003 174
0: No Fig. 3-6, (p. 3-11)
[spacer]
COMM1: Sig./meas.val.block.
037 075
0: No Fig. 3-7, (p. 3-12)
Fig. 3-8, (p. 3-13)
Fig. 3-9, (p. 3-14)
[spacer]
COMM1: IEC 870-5-103
003 219
0: No
[spacer]
COMM1: IEC 870-5-101
003 218
0: No
[spacer]
COMM1: IEC 870-5,ILS
003 221
0: No
[spacer]
COMM1: MODBUS
003 223
0: No
[spacer]
COMM1: DNP3
003 230
0: No
[spacer]
COMM1: COURIER
103 041
0: No
Parameter Address
Default Min Max Unit Logic Diagram
IEC 61850
Communication
IEC: Comm. link faulty
105 180
0: No
[spacer]
Display when an Ethernet module is not operational, i.e. if the MAC address is
missing or there is a non-plausible parameter setting.
P631
8 Information and Control Functions
8-26 P631/EN M/R-11-C // P631-310-650
