Parameter Address
Default Min Max Unit Logic Diagram
Main function
MAIN: Healthy
060 001
1: Yes
[spacer]
Signal that the protection unit is operational. By default this signal is linked to
LED: Fct.assig. H 1 green.
[spacer]
MAIN: Enable protect. EXT
003 027
2: Not configured
[spacer]
MAIN: Disable protect. EXT
003 026
2: Not configured
[spacer]
MAIN: Time switching EXT
003 096
0: Standard time
[spacer]
MAIN: Time synchronized
009 109
0: No
[spacer]
MAIN: Blocking 1 EXT
040 060
0: No
[spacer]
MAIN: K200 fail. cmd. end
221 108
0: No
[spacer]
In the case of direct motor control by motor relay K200 this signal is issued if the
K200 contacts have not reopened after the set monitoring time-delay has
elapsed.
[spacer]
MAIN: K200 fail. cmd.start
221 109
0: No
[spacer]
In the case of direct motor control by motor relay K200 this signal is issued if the
K200 contacts have not closed after the set monitoring time-delay has elapsed.
[spacer]
MAIN: DEV op.time exceeded
221 110
0: No
[spacer]
In the case of direct motor control by motor relay K200 this fault signal is issued
(as a group signal) when no positive position signal (status signal) has been
received from the external device after it has been issued a close command and
the set running time-delay has elapsed.
[spacer]
MAIN: Blocking 2 EXT
040 061
0: No
[spacer]
MAIN: Blocking 3 EXT
040 116
0: No
[spacer]
MAIN: Blocking 4 EXT
040 117
0: No
[spacer]
MAIN: Reset latch.trip EXT
040 138
0: No
P631
8 Information and Control Functions
8-42 P631/EN M/R-11-C // P631-310-650
