Micom P631 - Page 465

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Trip cmd. block. EXT
036 045
0: No
[spacer]
MAIN: Switch dyn.param.EXT
036 033
0: No
[spacer]
MAIN: Man. trip cmd. EXT
037 018
0: No
[spacer]
MAIN: CB1 open 3p EXT
031 028
0: No
[spacer]
MAIN: CB2 open 3p EXT
031 046
0: No
[spacer]
MAIN: CB1 closed 3p EXT
036 051
0: No
[spacer]
MAIN: CB2 closed 3p EXT
036 230
0: No
[spacer]
MAIN: Test mode EXT
037 070
0: No
[spacer]
MAIN: Reset indicat. EXT
065 001
0: No
[spacer]
MAIN: Group reset 1 EXT
005 209
2: Not configured
[spacer]
MAIN: Group reset 2 EXT
005 252
2: Not configured
[spacer]
MAIN: General reset EXT
005 255
0: No
[spacer]
MAIN: Reset c. cl/tr.c EXT
005 210
0: No
[spacer]
MAIN: Reset IP,max,st. EXT
005 211
0: No
[spacer]
MAIN: Min-pulse clock EXT
060 060
0: No
[spacer]
MAIN: Prot. ext. enabled
003 028
0: No Fig. 3-48, (p. 3-75)
[spacer]
MAIN: Prot. ext. disabled
038 046
1: Yes Fig. 3-48, (p. 3-75)
[spacer]
MAIN: Protect. not ready
004 060
1: Yes Fig. 3-52, (p. 3-79)
[spacer]
MAIN: Test mode
037 071
0: No Fig. 3-61, (p. 3-88)
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-43
