Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Blocked/faulty
004 065
1: Yes Fig. 3-52, (p. 3-79)
[spacer]
MAIN: Meas. circ.I faulty
036 155
0: No Fig. 3-51, (p. 3-78)
Fig. 3-125, (p. 3-157)
[spacer]
MAIN: Trip cmd. blocked
021 013
1: Yes Fig. 3-55, (p. 3-81)
[spacer]
MAIN: Latch. trip c. reset
040 139
0: No Fig. 3-55, (p. 3-81)
[spacer]
MAIN: Manual trip signal
034 017
0: No Fig. 3-55, (p. 3-81)
[spacer]
MAIN: Gen. trip signal
036 251
0: No Fig. 3-55, (p. 3-81)
[spacer]
MAIN: Gen. trip signal 1
036 005
0: No Fig. 3-55, (p. 3-81)
[spacer]
MAIN: Gen. trip signal 2
036 023
0: No
[spacer]
MAIN: Gen. trip signal 3
036 108
0: No
[spacer]
MAIN: Gen. trip signal 4
036 109
0: No
[spacer]
MAIN: Gen. trip command 1
036 071
0: No Fig. 3-55, (p. 3-81)
Fig. 3-114, (p. 3-149)
[spacer]
MAIN: Gen. trip command 2
036 022
0: No
[spacer]
MAIN: Gen. trip command 3
036 113
0: No
[spacer]
MAIN: Gen. trip command 4
036 114
0: No
[spacer]
MAIN: General starting
036 000
0: No Fig. 3-53, (p. 3-80)
[spacer]
MAIN: Trip sig.REF1 & REF2
036 174
0: No
[spacer]
MAIN: Trip sig.REF2 & REF3
036 175
0: No
[spacer]
MAIN: Trip sig.REF1 & REF3
036 176
0: No
