Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
MAIN: Dynam. param. active
040 090
0: No Fig. 3-49, (p. 3-76)
[spacer]
MAIN: Phase reversal activ
036 220
0: No Fig. 3-42, (p. 3-66)
[spacer]
MAIN: CB1 open 3p
031 040
0: No
[spacer]
MAIN: CB2 open 3p
031 086
0: No
[spacer]
MAIN: CB1 closed 3p
031 042
0: No
[spacer]
MAIN: CB2 closed 3p
031 089
0: No
[spacer]
MAIN: CB1 pos.sig. implaus
031 041
0: No
[spacer]
MAIN: CB2 pos.sig. implaus
031 049
0: No
[spacer]
MAIN: CB failure
036 017
0: No Fig. 3-131, (p. 3-164)
[spacer]
MAIN: Startcmdtime exceed.
221 112
0: No
[spacer]
If the monitoring, set by DEV01: StartCmdTime superv. (or
DEV02: StartCmdTime superv. etc.), is active then an exceeded timer is
flagged by this logic state signal.
[spacer]
MAIN: Without function
060 000
0: No
[spacer]
MAIN: Without function
061 000
0: No
8 Information and Control Functions
