Parameter Address
Default Min Max Unit Logic Diagram
Differential protec‐
tion
DIFF: Enabled
041 210
0: No Fig. 3-77, (p. 3-110)
[spacer]
DIFF: Starting
041 106
0: No
[spacer]
DIFF: Meas.system 1 trigg.
041 124
0: No Fig. 3-85, (p. 3-118)
[spacer]
DIFF: Meas.system 2 trigg.
041 125
0: No Fig. 3-85, (p. 3-118)
[spacer]
DIFF: Meas.system 3 trigg.
041 126
0: No Fig. 3-85, (p. 3-118)
[spacer]
DIFF: Id>> triggered
041 221
0: No Fig. 3-85, (p. 3-118)
[spacer]
DIFF: Id>>> triggered
041 222
0: No Fig. 3-85, (p. 3-118)
[spacer]
DIFF: Harm.block 1 trigg.
041 118
0: No Fig. 3-86, (p. 3-119)
[spacer]
DIFF: Harm.block 2 trigg.
041 119
0: No Fig. 3-86, (p. 3-119)
[spacer]
DIFF: Harm.block 3 trigg.
041 120
0: No Fig. 3-86, (p. 3-119)
[spacer]
DIFF: Overflux.bl.1 trigg.
041 121
0: No Fig. 3-88, (p. 3-121)
[spacer]
DIFF: Overflux.bl.2 trigg.
041 122
0: No Fig. 3-88, (p. 3-121)
[spacer]
DIFF: Overflux.bl.3 trigg.
041 123
0: No Fig. 3-88, (p. 3-121)
[spacer]
DIFF: Sat.discr. 1 trigg.
041 115
0: No Fig. 3-87, (p. 3-120)
[spacer]
DIFF: Sat.discr. 2 trigg.
041 116
0: No Fig. 3-87, (p. 3-120)
[spacer]
DIFF: Sat.discr. 3 trigg.
041 117
0: No Fig. 3-87, (p. 3-120)
[spacer]
DIFF: Trip signal
041 075
0: No Fig. 3-85, (p. 3-118)
[spacer]
DIFF: Trip signal 1
041 002
0: No Fig. 3-85, (p. 3-118)
