Micom P631 - Page 475

Parameter Address
Default Min Max Unit Logic Diagram
Overload recording
OL_RC: Reset record. EXT
005 241
0: No
[spacer]
OL_RC: Record. in progress
035 003
0: No Fig. 3-68, (p. 3-98)
[spacer]
OL_RC: Overl. mem. overflow
035 007
0: No Fig. 3-69, (p. 3-99)
Parameter Address
Default Min Max Unit Logic Diagram
Fault recording
FT_RC: Reset record. EXT
005 243
0: No
[spacer]
FT_RC: Trigger EXT
036 089
0: No
[spacer]
FT_RC: Trigger
037 076
0: No Fig. 3-74, (p. 3-105)
[spacer]
FT_RC: Id> triggered
035 018
0: No
[spacer]
FT_RC: IR> triggered
035 019
0: No
[spacer]
FT_RC: Record. in progress
035 000
0: No Fig. 3-74, (p. 3-105)
[spacer]
FT_RC: System disturb. runn
035 004
0: No Fig. 3-74, (p. 3-105)
[spacer]
FT_RC: Fault mem. overflow
035 001
0: No Fig. 3-75, (p. 3-106)
[spacer]
FT_RC: Faulty time tag
035 002
0: No
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-53
