Micom P631 - Page 474

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
SFMON: Output 30
098 053
0: No
[spacer]
SFMON: Output 30 (t)
098 054
0: No
[spacer]
SFMON: Output 31
098 055
0: No
[spacer]
SFMON: Output 31 (t)
098 056
0: No
[spacer]
SFMON: Output 32
098 057
0: No
[spacer]
SFMON: Output 32 (t)
098 058
0: No
[spacer]
SFMON: CB1 pos.sig. implaus
098 124
0: No
[spacer]
SFMON: CB2 pos.sig. implaus
098 125
0: No
[spacer]
SFMON: CB1 faulty EXT
098 072
0: No
[spacer]
SFMON: CB2 faulty EXT
098 129
0: No
Parameter Address
Default Min Max Unit Logic Diagram
Operating data
recording
OP_RC: Reset record. EXT
005 213
0: No Fig. 3-59, (p. 3-85)
Parameter Address
Default Min Max Unit Logic Diagram
Monitoring signal
recording
MT_RC: Reset record. EXT
005 240
0: No
P631
8 Information and Control Functions
8-52 P631/EN M/R-11-C // P631-310-650
