Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
SFMON: Meas. circ. I faulty
091 018
0: No Fig. 3-51, (p. 3-78)
Fig. 3-125, (p. 3-157)
[spacer]
SFMON: Meas. c. I faulty, a
091 026
0: No Fig. 3-124, (p. 3-157)
[spacer]
SFMON: Meas. c. I faulty, b
091 027
0: No
[spacer]
SFMON: Invalid charact. V/f
091 011
0: No
[spacer]
SFMON: Invalid SW vers DHMI
093 145
0: No
[spacer]
SFMON: Invalid scaling BCD
093 124
0: No
[spacer]
SFMON: Invalid scaling A-1
093 114
0: No Fig. 3-36, (p. 3-57)
[spacer]
SFMON: Invalid scaling A-2
093 115
0: No
[spacer]
SFMON: Invalid scaling IDC
093 116
0: No Fig. 3-26, (p. 3-41)
[spacer]
SFMON: Iref, a inval. range
091 007
0: No Fig. 3-78, (p. 3-111)
[spacer]
SFMON: Iref, b inval. range
091 008
0: No Fig. 3-78, (p. 3-111)
[spacer]
SFMON: Matching fail. end a
091 000
0: No Fig. 3-78, (p. 3-111)
[spacer]
SFMON: Matching fail. end b
091 001
0: No Fig. 3-78, (p. 3-111)
[spacer]
SFMON: Ratio mtch.fact.inv.
091 004
0: No
[spacer]
SFMON: 2nd match.fact. inv.
091 006
0: No Fig. 3-78, (p. 3-111)
[spacer]
SFMON: CTA error THRM1
098 036
0: No Fig. 3-113, (p. 3-148)
[spacer]
SFMON: Setting error THRM1
098 038
0: No Fig. 3-114, (p. 3-149)
[spacer]
SFMON: Inv.inp.f.clock sync
093 120
0: No
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-51
