Micom P631 - Page 488

Parameter Address
Default Min Max Unit Logic Diagram
Thermal overload
protection
THRM1: Replica block EXT
039 150
0: No
[spacer]
THRM1: CTA error EXT
039 152
0: No
[spacer]
THRM1: Reset replica EXT
039 122
0: No
[spacer]
THRM1: Enabled
039 129
0: No Fig. 3-110, (p. 3-145)
[spacer]
THRM1: Not ready
039 154
1: Yes Fig. 3-111, (p. 3-146)
[spacer]
THRM1: Reset replica
039 125
0: No Fig. 3-115, (p. 3-150)
[spacer]
THRM1: Buffer empty
039 128
1: Yes
[spacer]
THRM1: CTA error
039 127
0: No Fig. 3-113, (p. 3-148)
[spacer]
THRM1: Starting k*Iref>
039 151
0: No Fig. 3-114, (p. 3-149)
[spacer]
THRM1: Within pre-trip time
039 153
1: Yes Fig. 3-114, (p. 3-149)
[spacer]
THRM1: Warning
039 124
0: No Fig. 3-114, (p. 3-149)
[spacer]
THRM1: Trip signal
039 123
0: No Fig. 3-114, (p. 3-149)
[spacer]
THRM1: Setting error,block.
039 126
0: No Fig. 3-114, (p. 3-149)
P631
8 Information and Control Functions
8-66 P631/EN M/R-11-C // P631-310-650
