Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
CBF_1: Trip signal
040 026
0: No Fig. 3-133, (p. 3-165)
[spacer]
CBF_1: CB pos. implausible
038 210
0: No Fig. 3-129, (p. 3-162)
[spacer]
CBF_1: Fault behind CB
038 225
0: No Fig. 3-134, (p. 3-165)
[spacer]
CBF_1: CBsync.superv A open
038 227
0: No Fig. 3-135, (p. 3-166)
[spacer]
CBF_1: CBsync.superv B open
038 228
0: No Fig. 3-135, (p. 3-166)
[spacer]
CBF_1: CBsync.superv C open
038 229
0: No Fig. 3-135, (p. 3-166)
[spacer]
CBF_1: TripSig CBsync.super
038 226
0: No Fig. 3-135, (p. 3-166)
[spacer]
CBF_1: Current flow A
038 230
0: No Fig. 3-128, (p. 3-161)
[spacer]
CBF_1: Current flow B
038 231
0: No Fig. 3-128, (p. 3-161)
[spacer]
CBF_1: Current flow C
038 232
0: No Fig. 3-128, (p. 3-161)
[spacer]
CBF_1: Current flow Phx
038 233
0: No Fig. 3-128, (p. 3-161)
[spacer]
CBF_1: Current flow N
038 235
0: No Fig. 3-128, (p. 3-161)
[spacer]
Signal that the residual current is greater than the set value CBF_1: IN<.
P631
8 Information and Control Functions
8-70 P631/EN M/R-11-C // P631-310-650
