Micom P631 - Page 491

Parameter Address
Default Min Max Unit Logic Diagram
Circuit breaker
failure protection
CBF_1: Enable EXT
038 041
2: Not configured
[spacer]
CBF_1: Disable EXT
038 042
2: Not configured
[spacer]
CBF_1: Blocking EXT
038 058
0: No
[spacer]
CBF_1: CB faulty EXT
038 234
0: No
[spacer]
CBF_1: Start enable EXT
038 209
1: Yes
[spacer]
CBF_1: Start 3p EXT
038 205
0: No
[spacer]
CBF_1: Starting trig. EXT
038 016
0: No
[spacer]
CBF_1: Ext./user enabled
038 040
1: Yes Fig. 3-126, (p. 3-159)
[spacer]
CBF_1: Enabled
040 055
0: No Fig. 3-126, (p. 3-159)
[spacer]
CBF_1: Ready
038 009
0: No Fig. 3-127, (p. 3-160)
[spacer]
CBF_1: Not ready
040 025
1: Yes Fig. 3-127, (p. 3-160)
[spacer]
CBF_1: Startup 3p
038 211
0: No Fig. 3-130, (p. 3-163)
[spacer]
CBF_1: Trip signal t1
038 215
0: No Fig. 3-131, (p. 3-164)
[spacer]
CBF_1: Trip signal t2
038 219
0: No Fig. 3-131, (p. 3-164)
[spacer]
CBF_1: Trip command t1
038 220
0: No Fig. 3-132, (p. 3-164)
[spacer]
CBF_1: Trip command t2
038 224
0: No Fig. 3-132, (p. 3-164)
[spacer]
CBF_1: CB failure
043 181
0: No
[spacer]
CBF_1: Starting
038 021
0: No Fig. 3-133, (p. 3-165)
