Parameter Address
Default Min Max Unit Logic Diagram
IEC Generic
Substation Status
Events
GSSE: Reset statistics
105 171
0: don't execute
[spacer]
Command to reset monitoring counters as listed below.
[spacer]
GSSE: Enroll. IEDs flags L
105 160
Not measured 0 65535
[spacer]
Bar with state bits for all GSSE inputs, showing if the respective GSSE sending
device has logged-on and is transmitting free of fault (input 1 to 16).
[spacer]
GSSE: Enroll. IEDs flags H
105 161
Not measured 0 65535
[spacer]
Bar with state bits for all GSSE inputs, showing if the respective GSSE sending
device has logged-on and is transmitting free of fault (input 17 to 32).
[spacer]
GSSE: Tx message counter
105 162
Not measured 0 65535
[spacer]
Shows the number of GSSE messages sent. This counter is reset by
GSSE: Reset statistics.
[spacer]
GSSE: Rx message counter
105 163
Not measured 0 65535
[spacer]
Shows the number of GSSE messages received. This counter is reset by
GSSE: Reset statistics.
[spacer]
GSSE: No. bin.state chang.
105 164
Not measured 0 65535
[spacer]
Number of state changes included in a GSSE sent. This counter is reset by
GSSE: Reset statistics.
[spacer]
GSSE: Tx last sequence
105 165
Not measured 0 65535
[spacer]
State of the continuous counter sequence for the message counter sent with
each GSSE.
[spacer]
GSSE: Tx last message
105 166
Not measured 0 65535
[spacer]
State of the continuous counter sequence for state changes sent with each
GSSE.
[spacer]
GSSE: No. reject. messages
105 167
Not measured 0 65535
[spacer]
Number of telegram rejections having occurred because of non-plausible
message content. This counter is reset by GSSE: Reset statistics.
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-85
