Parameter Address
[spacer]
SFMON: Wrong module slot 10
096 109
[spacer]
Module in wrong slot.
1st device reaction: Warm restart
2nd device reaction: Device blocking
'Warning' output relay: Yes
'Blocked/faulty' output relay: Yes
[spacer]
SFMON: Wrong module Dig.Bus
096 123
[spacer]
The device has been fitted with a wrong digital bus. Since this is checked using
the module variant number this signal can also occur after a firmware upgrade
to a version that is not compatible with the hardware.
1st device reaction: Warm restart
2nd device reaction: Device blocking
'Warning' output relay: Yes
'Blocked/faulty' output relay: Yes
[spacer]
SFMON: Wrong module HMI
096 124
[spacer]
The device has been fitted with a wrong HMI. Since this is checked using the
module variant number this signal can also occur after a firmware upgrade to a
version that is not compatible with the hardware.
1st device reaction: Warm restart
2nd device reaction: Device blocking
'Warning' output relay: Yes
'Blocked/faulty' output relay: Yes
[spacer]
SFMON: Wrong module Comm
096 125
[spacer]
The device has been fitted with a wrong communication module. Since this is
checked using the module variant number this signal can also occur after a
firmware upgrade to a version that is not compatible with the hardware.
1st device reaction: Warm restart
2nd device reaction: Device blocking
'Warning' output relay: Yes
'Blocked/faulty' output relay: Yes
[spacer]
SFMON: Wrong module Ana.Bus
096 126
[spacer]
The device has been fitted with a wrong analog bus. Since this is checked using
the module variant number this signal can also occur after a firmware upgrade
to a version that is not compatible with the hardware.
1st device reaction: Warm restart
2nd device reaction: Device blocking
'Warning' output relay: Yes
'Blocked/faulty' output relay: Yes
[spacer]
SFMON: Defect.module slot 1
097 000
[spacer]
SFMON: Defect.module slot 2
097 001
[spacer]
SFMON: Defect.module slot 3
097 002
P631
11 Troubleshooting
11-4 P631/EN M/R-11-C // P631-310-650
