Parameter Address
[spacer]
SFMON: Output 30
098 053
[spacer]
SFMON: Output 30 (t)
098 054
[spacer]
SFMON: Output 31
098 055
[spacer]
SFMON: Output 31 (t)
098 056
[spacer]
SFMON: Output 32
098 057
[spacer]
SFMON: Output 32 (t)
098 058
[spacer]
These LOGIC outputs can be included in the list of warning signals by selection
at SFMON: Fct. assign. warning. The warning signals are also recorded
in the monitoring signal memory.
'Warning' output relay: Yes
'Blocked/faulty' output relay: –
[spacer]
SFMON: CB1 pos.sig. implaus
098 124
[spacer]
SFMON: CB2 pos.sig. implaus
098 125
[spacer]
The plausibility logic was triggered during the acquisition of the circuit breaker's
(CB) status signals.
'Warning' output relay: Yes
'Blocked/faulty' output relay: –
[spacer]
SFMON: CB1 faulty EXT
098 072
[spacer]
SFMON: CB2 faulty EXT
098 129
[spacer]
The external input CBF_1: CB faulty EXT has become active.
Device reaction: –
'Warning' output relay: Yes
'Blocked/faulty' output relay: –
P631
11 Troubleshooting
11-12 P631/EN M/R-11-C // P631-310-650
