Version Changes
As an ordering option for the 40TE and 84TE model
versions there is now a variant available with a
detachable HMI. The detachable HMI is always supplied
with a case width of 40TE.
The detachable HMI provides the following new
features:
●
6 freely configurable function keys as well as 6
freely configurable LED indicators (H18 to H23)
each situated next to a function key.
●
The freely configurable LED indicators (H4 to H16
and H18 to H23) are provided as multi-color LEDs.
Note:
When the local control panel is ordered together with a
detachable HMI for hardware version -306, it is
delivered with function keys and multi-colored LED
indicators fitted. Otherwise the earlier local control
panel is delivered without having function keys and
multi-colored LED indicators fitted.
With hardware version -307 and irrelevant of the
ordering option, the local control panel is delivered with
function keys and multi-colored LED indicators fitted.
Diagram
The updated connection diagrams now include the
interfaces to connect the detachable HMI.
●
P631.405 (for 40TE case, pin-terminal connection)
●
P631.406 (for 84TE case, ring-terminal
connection)
Software
LOC, MAIN Respective binary signal inputs (if previously
unavailable) are assigned to all default reset functions.
These binary input functions are now available in the
configuration list for the two newly implemented group
resetting functions as well as the extended functional
assignment for the CLEAR key ('C'):
●
(005 248) MAIN: Fct.assign. reset 1
●
(005 249) MAIN: Fct.assign. reset 2
●
(005 251) LOC: Assignment reset key
Two menu jump lists may now be configured. These
menu jump lists make it possible to select individual
menu points (i.e. set values, counters, triggering
functions, event logs) in a freely definable sequence.
●
(030 238) LOC: Fct. menu jmp list 1
●
(030 239) LOC: Fct. menu jmp list 2
A5 P631 Version History
P631
P631/EN M/R-11-C // P631-310-650 A5-11
