Version Changes
CBF_x The release condition for the function has been
dissociated from the drop-out of the internal trip signal.
Therefore the sequence will now only be stopped when
a loss of load/undercurrent condition has occurred or
when the CB signals that its contacts are open.
Bug fixing:
●
The time tags for the CBF_1: Ready (038 009)
and CBF_2: Ready (043 076) spontaneous
signals (according to the communications
protocol per IEC-60870-5-10x) and the entry in
the operating data memory did not match.
P631
‑308
‑407/408
‑621
Release: 2009-01-08
Hardware
No changes.
Diagram
No changes.
Software
IEC The data object LN_CFG has been extended in logical
nodes Dt1NgsPTOC1, Dt2NgsPTOC1 and Dt3NgsPTOC1.
The following logical node has been added:
●
PloGGIO4
The AlmGGIO logical node has been extended by the
following signals:
●
Alm5: THRM1: CTA error (039 127)
●
Alm7: MEASI: PT100 faulty (040 190)
●
Alm8: MEASI: Overload 20mA input (040
191)
●
Alm9: MEASI: Open circ. 20mA inp. (040
192)
●
Alm10: CTS: Operated (updating) (036 099)
The ‘Bl.f.’ data objects are now available in all nodes:
PTOC, PTOV, PTUV, PTTR, PTOF, PTUF, RBRF, PVPH.
Because of this, the ‘Blocking EXT’ condition has been
removed from the ‘MODE’.
The parameter at address (104 232) IEC: Dead band
VPP has been renamed to IEC: Dead band V.
Since the corresponding measured values are not
provided by the P631, the following addresses have
been deleted:
●
IEC: Dead band VPG (104 233)
●
IEC: Dead band P (104 235)
●
IEC: Dead band Z (104 237)
●
IEC: Dead band ASC (104 239)
●
IEC: Update cycle energy (104 060)
P631
A5 P631 Version History
A5-18 P631/EN M/R-11-C // P631-310-650
