Appendix| Control Menu
optoNCDT 1420
A 4.2.3 Outputs
RS422 Baud rate 9.6 / 19.2 / 56.0 / 115.2 / 230.4 ... / 1000 kBps Transmission speed, binary data format
Output data Distance / Exposure time / Intensity /
Sensor status / Measurement value counter /
non-inearized focus /
Timestamp / Video raw signal
Date to be transmitted are to be activated via the
checkbox.
Analog output Standard scaling Start of measuring range 4 mA,
at end of measuring range 20 mA
Two point scaling Start of range Value Always 2 points are taught which mark start and
end of new measuring range. With two point
scaling reversal of the output signal is possible.
End of range Value
Digital output Inactive Regulates the switching performance of the
digital output (Error), see Chap. 5.4.8.
Analog range: digital output switches when the
scaled analog range is exceeded.
Measuring range: The digital output is switched
when the peak is not (entirely) in evaluation
range (ROI).
Limit monitoring: digital output switches when
the limit is exceeded.
Analog range
Measuring range
NPN / PNP / PushPull / PushPullNeg
Limit monitoring NPN / PNP / PushPull / PushPullNeg
Limit Value
Hysteresis Value
Minimum holding
period
Value
Data output Web interface / Analog / RS422 Decides on the used interface for measurement
value output. A parallel physical measurement
value output via RS422 and analog is not pos-
sible. If web interface was selected, no measure-
ment values are output via RS422 or current
output.
