Page 64
Set Sensor Parameter
optoNCDT 1420
7.5 Outputs
7.5.1 Overview
RS422 Baud rate 9.6 / 19.2 / 56.0 / 115.2 / 230.4 ... /
1000 kBps
Transmission rate with binary data
format.
Output data Distance / Shutter time / Intensity /
Sensor state / Measurement counter /
Non-linearized focal point /
Time stamp / Video raw signal
The data which are provided for the
transmission are to activate with
the checkbox.
Analog output Standard scale Start of measuring range 4 mA,
end of measuring range 20 mA
Two-point
scale
Minimum value Value Always 2 points which mark the
start and end of a new measuring
range are taught. Reversal of the
output signal is possible with two-
point scaling.
Maximum value Value
Digital output Inactive Adjusts the switching characteristic
of the digital output (error), see
Chap. 5.4.8.
Full scale error NPN / PNP / PushPull / PushPullNeg
Output Interface Web interface / Analog / RS422 Decides via the used interface for
measurement output. A parallel
measurement output via multiple
channels is not possible. When
choosing web interface measure-
ment values are not output via
RS422 or current output.
Grey shaded
fields require a
selection.
Value
Dark-bordered
fields require you
to specify a value.
