Page 99
Appendix| ASCII Communication with Sensor
optoNCDT 1420
A 3.3.7 PRINT, Sensor Settings
PRINT
Print serves the output of all sensor settings.
Example of an answer:
GETUSERLEVEL PROFESSIONAL OUTPUT ANALOG
STDUSER PROFESSIONAL OUTREDUCEDEVICE NONE
BAUDRATE 921600 OUTREDUCECOUNT 2
UNIT MM OUTVIDEO_RS422 NONE
LANGUAGE DE OUTADD_RS422 NONE
MFIFUNC NONE GETOUTINFO_RS422 DIST1
MFILEVEL HTL_HIGH OUTHOLD NONE
KEYFUNC NONE ERROROUT1 DIST
KEYLOCK AUTO 5 (IS_ACTIVE) ERRORLEVELOUT1 NPN
TARGETMODE STANDARD ANALOGSCALE STANDARD
MEASRATE 2.000
MEASPEAK DISTA ->
ROI 0 511
AVERAGE MEDIAN 9
TRIGGERAT INPUT
TRIGGER NONE
TRIGGERCOUNT INFINITE
LASERPOW FULL
MASTERMV NONE
