Page 17
Functional Principle, Technical Data
optoNCDT 1420
3.3 Technical Data ILD1420
Model ILD1420-10 ILD1420-25 ILD1420-50 ILD1420-100 ILD1420-200 ILD1420-500
Measuring range 10 mm 25 mm 50 mm 100 mm 200 mm 500 mm
Start of measuring range 20 mm 25 mm 35 mm 50 mm 60 mm 100 mm
Midrange 25 mm 37.5 mm 60 mm 100 mm 160 mm 350 mm
End of measuring range 30 mm 50 mm 85 mm 150 mm 260 mm 600 mm
Linearity
1
8 ... 10 µm 20 ... 25 µm 40 ... 50 µm 80 ... 100 µm 160 ... 200 µm 500 ... 1000 µm
≤0.08-0.1%FSO ≤0.1-0.2%FSO
Reproducibility
2
0.5 µm 1 µm 2 µm 4 µm 8 µm 20 ... 40 µm
Measuring rate
3
0.25 kHz / 0.5 kHz / 1 kHz / 2 kHz / 4 kHz
Light source semiconductor laser <1 mW, 670 nm (red)
Permissible ambient light 10,000 lx
Spot diameter
± 10 %
SMR 90 x 120 µm 100 x 140 µm 90 x 120 µm
750 x 1100 µm 750 x 1100 µm 750 x 1100 µmMMR 45 x 40 µm 120 x 130 µm 230 x 240 µm
EMR 140 x 160 µm 390 x 500 µm 630 x 820 µm
smallest ø
45 x 50 µm
at 24 mm
55 x 50 µm
at 31 mm
70 x 65 µm
at 42 mm
--- --- ---
Laser safety class class 2 IEC 60825-1: 2015-07
Temperature stability ± 0.03 % FSO/°C
Operation temperature 0 ... +50 °C (non-condensing)
Storage temperature -20 ... +70 °C (non-condensing)
Output
analog
4 ... 20mA (1 ... 5V with cable PCF1420-3/U); 12 bit
free scalable within the nominal range
4
digital RS422 / 16 bit resp. 18 bit
Vibration 20 g / 20 ... 500 Hz (acc. to IEC 60068-2-6)
