Page 20
Functional Principle, Technical Data
optoNCDT 1420
Schock 15 g / 6 ms / 3 axes (acc. to IEC 60068-2-29)
Weight
appr. 145 g (with cable 3 m)
appr. 60 g (with Pigtail)
Control I/O
input
laser on/off;
funktional input: trigger / zero-setting / mastering / teaching
output digital output
Sensor cable
3 m, integrated, open ends
0.3 m Pigtail with 12pin M12 connector
LED 2 x 3 color LEDs for power and status
Key select key for zero / teaching / factory setting
Power supply 11-30V DC, 24 V, P< 2 W
Controller integrated signal processor
The specified data apply for a diffusely reflecting matt white ceramic target.
FSO = Full scale output
SMR = Start of measuring range; MR = Midrange; EMR = End of measuring range
1) Values are valid from 0 to 50 % FSO resp. 51 to 100 % FSO.
2) Measuring rate 2 kHz, median 9
3) Factory setting 2 kHz; to change the factory setting requires an IF2001/USB converter (optionaly available)
4) D/A conversion is executed with 12 bit;
