Set Sensor Parameter
optoNCDT 1420
643
0
Reserve Messbereich
0 % 50 %
MB
32760
64877
52031
Dig.
Out
65520
Standard-Ausgangskennlinie
100 %
Fig. 37 Digital values without zero setting resp.
mastering
Set target at 80 % measuring range (40 mm), set master value 100 mm
643
0
Reserve
Measuring
range
50-25 0
Distance after
mastering
[mm]
225465
161230
96995
109200
174077
174720
109843
32760
Digital
Out
100SMR‘ EMR‘
MP‘
150
Reserve
measuring
range
Fig. 38 Digital values of an ILD1420-50 with mastering, master value 100 mm
