MICRO-EPSILON ILD 1420-10 User Manual

Page 73
Set Sensor Parameter
optoNCDT 1420
Current output (with teaching)
Variables Value range Formula
I
OUT
= current [mA]
[3,8; <4] SMR reserve
[4; 20] measuring range
[>20; 20,2] EMR reserve
d [mm] =
16
*|n [mm] - m [mm]|
(I
OUT
[mA] - 4)
MR = measuring range [mm] {10/25/50/100/200/500}
m, n = teaching area [mm] [0; MR]
d = distance [mm] [m; n]
Current output (with mastering and teaching)
Variables Value range Formula
I
OUT
= current [mA]
[3,8; <4] SMR reserve
[4; 20] measuring range
[>20; 20,2] EMR reserve
d
[mm] = * |n [mm] - m [mm]
|
(I
OUT
[mA] - 12)
16
MR = measuring range [mm] {10/25/50}
MP = position object [mm] [0; MR]
m, n = teaching area [mm]
for MP £ 0.5MR: [-MP; 0.5MR]
for MP > 0.5MR: [-0,5MR; MR - MP]
d = distance [mm] [m; n]
