Midas PRO6

About the Patching screen 61
PRO6 Live Audio System
Owner’s Manual
Mon. (Monitor) tab
The Mon. (Monitor) tab allows routing of
the monitor outs (A and B) and external
talk.
These can also be found on the Monitors
screen (see Figure 29 “Monitor A and B in
the master bay” on page 198) as shown in
the following table.
About the tabs in the To section
The To section contains all of the destination patch connectors on tabs.
For details of where you can access the tab sheets in the From and To sections from,
see “Navigating to the Patching screen” on page 64.
Stage I/O tab
Although this is the equivalent of the Stage I/O tab in the From section, this one does
not contain any mic splitters, as they don’t supply any inputs to the PRO6 Control
Centre. Refer to Figure >>, “To access the Patching screen,” on page 56 and “System
components (standard supply)” on page 8.
FOH I/O tab
This tab is the equivalent of the FOH I/O
tab in the From section (see “FOH I/O tab”
on page 59).
For information on what devices can be
fitted in the I/O rack, see “About the
devices on the stage and FOH I/O tabs” on
page 64.
Mon. tab output Equivalent on the Monitors screen
Monitor Out A L monitor A output L
Monitor Out A R monitor A output R
Monitor Out B L monitor B output L
Monitor Out B R monitor B output R
Monitor Out C L monitor centre output
Monitor Out C R monitor LFE output
External Talk Destination external talk output
