13.7.6. DeviceNet parameters
This sets the DeviceNet information in the robot controller.
Set parameters while connected to the robot controller.
Double-click [Field network parameter] -> [DeviceNet] under the [Parameter] item to be edited from the project
tree.
After you change a parameter value, you can rewrite the parameters in the robot controller by clicking the [Write]
button.
Figure 13-74 DeviceNet parameters
You can reset DeviceNet interface card errors by pressing the [Err. Cancel] button. After that the same error will
not occur. It is valid while the power supply of the robot controller is ON. When the power supply is turned OFF,
the error may occur again.
You can reference explanation of the displayed parameters by pressing the [Explain] button.
This function can only be used with CR800-D/CR750-D/CRnD-700/CRn-500 series robot controllers.
Caution
