12 DATA USED FOR POSITIONING CONTROL
12.4 Positioning Data
[Da.1] Operation pattern
The operation pattern designates whether positioning of a certain data No. is to be ended with just that data, or whether the
positioning for the next data No. is to be carried out in succession.
[Da.2] Control method
Set the "control method" for carrying out positioning control.
• When "JUMP instruction" is set for the control method, the "[Da.9] Dwell time/JUMP destination positioning
data No." and "[Da.10] M code/Condition data No./Number of LOOP to LEND repetitions/Number of
pitches" setting details will differ.
• In case you selected "LOOP" as the control method, the "[Da.10] M code/Condition data No./Number of
LOOP to LEND repetitions/Number of pitches" should be set differently from other cases.
• Refer to the following for details on the control methods.
Page 48 MAJOR POSITIONING CONTROL
• If "degree" is set for "[Pr.1] Unit setting", circular interpolation control and 3-axis helical interpolation control
cannot be carried out. (The error "Circular interpolation not possible" (error code: 199FH) will occur when
executed.)
[Da.3] Acceleration time No.
Set which of "acceleration time 0 to 3" to use for the acceleration time during positioning.
0: Use the value set in "[Pr.9] Acceleration time 0".
1: Use the value set in "[Pr.25] Acceleration time 1".
2: Use the value set in "[Pr.26] Acceleration time 2".
3: Use the value set in "[Pr.27] Acceleration time 3".
Positioning
option
[Da.27]
M code ON
signal output
timing
0: Uses the setting value of "[Pr.18] M
code ON signal output timing".
1: WITH mode
2: AFTER mode
0
1
2
0000H 6003+1000n
[Da.28]
ABS
direction in
degrees
0: Uses the setting value of "[Cd.40] ABS
direction in degrees".
1: ABS circular right
2: ABS circular left
3: Takes a shortcut. (Specified direction
ignored.)
0
1
2
3
[Da.29]
Interpolation
speed
designation
method
0: Uses the setting value of "[Pr.20]
Interpolation speed designation
method".
1: Composite speed
2: Reference axis speed
0
1
2
Operation pattern Setting value Details
Positioning complete 00 Set to execute positioning to the designated address, and then complete positioning.
Continuous positioning control 01 Positioning is carried out successively in order of data Nos. with one start signal. The operation halts at
each position indicated by a positioning data.
Continuous path control 11 Positioning is carried out successively in order of data Nos. with one start signal. The operation does
not stop at each positioning data.
Item Setting value Default
value
Buffer memory
address
Value set with the engineering tool Value set with a program
Not used*
b0b4b8b12b15
[Da.29]
[Da.28] [Da.27]
*: Always "0" is set to the part not used.
