3 SPECIFICATIONS
The following gives the detailed explanation of control data, program pattern, and
zone PID data.
(a) Control data
Common data required for executing the program control are sets.
Buffer memory address (Decimal)
Buffer memory name Description
CH1 CH2
Execution pattern
setting
Sets a program to be executed selecting from the
program patterns 1 to 3
272 528
Start mode Sets a starting method of set value (SV) selecting
from zero starting/PV starting 1/ PV starting 2.
273 529
Time scale Sets the executing time scale of the segment set in
program pattern data.
274 530
(b) Program pattern data
Program pattern consists of segments, which have set value, time (execution
time), and zone PID data No.
The Q62HLC can set up to 3 patterns of 16-segment program pattern at the
maximum.
Several program patterns can be linked by pattern link (refer to the next page for
buffer memories).
Pattern 3
Pattern 2
Pattern 1
Final segment
Pattern link
Iteration
Output time of pattenend
Wait zone
Segment 1
Segment 2
Segment 16
Set value (SV)
Executing time
Zone PID data No.
Each segment

Mitsubishi Q Series Specifications

General

I/O Points	Up to 4096 points
Communication	Ethernet, RS-232, RS-485
I/O Modules	Digital, Analog, Specialized
Programming Language	Function Block Diagram, Structured Text
Power Supply	24V DC, 100-240V AC
Operating Temperature	0°C to 55°C
Shock Resistance	147 m/s2 acceleration, 3 times in each of X, Y, and Z directions
Program Capacity	Up to 252K steps
