3 - 26 3 - 26
MELSEC-Q
3 SPECIFICATIONS
Buffer memory address (Decimal)
Program pattern
Buffer memory name Description CH
1 2 3
1 320 384 448 Final segment Sets the final segment to complete the
program pattern.
2 576 640 704
1 321 385 449 Pattern link Sets the program pattern of link destination
when linking several program patterns.
2 577 641 705
1 322 386 450 Iteration Sets execution times of the program control.
2 578 642 706
1 323 387 451 Output time of pattern end Sets the pattern end output time when
completing the program pattern.
2 579 643 707
1 324 388 452 Wait zone Sets a zone where the program control waits
before moving to next segment when the
measured value cannot follow the progress of
the program control.
2 580 644 708
*1: When the program pattern has been linked, the program pattern setting, which is set at the
execution pattern setting (buffer memory address: 272,528), is valid.
*2: When the program pattern has been linked, the setting of the executing program pattern is valid.
Buffer memory address (Decimal)
Program pattern
1 2 3
Buffer memory name Description Segment
CH1 CH2 CH1 CH2 CH1 CH2
1 325 581 389 645 453 709
2 328 584 392 648 456 712
3 331 587 395 651 459 715
4 334 590 398 654 462 718
5 337 593 401 657 465 721
6 340 596 404 660 468 724
7 343 599 407 663 471 727
8 346 602 410 666 474 730
9 349 605 413 669 477 733
10 352 608 416 672 480 736
11 355 611 419 675 483 739
12 358 614 422 678 486 742
13 361 617 425 681 489 745
14 364 620 428 684 492 748
15 367 623 431 687 495 751
Set value (SV) setting Sets the set value of segment.
16 370 626 434 690 498 754
To Next Page
