3 - 27 3 - 27
MELSEC-Q
3 SPECIFICATIONS
(From previous page)
Buffer memory address (Decimal)
Program pattern
1 2 3
Buffer memory name Description Segment
CH1 CH2 CH1 CH2 CH1 CH2
1 326 582 390 646 454 710
2 329 585 393 649 457 713
3 332 588 396 652 460 716
4 335 591 399 655 463 719
5 338 594 402 658 466 722
6 341 597 405 661 469 725
7 344 600 408 664 472 728
8 347 603 411 667 475 731
9 350 606 414 670 478 734
10 353 609 417 673 481 737
11 356 612 420 676 484 740
12 359 615 423 679 487 743
13 362 618 426 682 490 746
14 365 621 429 685 493 749
15 368 624 432 688 496 752
Executing time
Sets the execution time of
segments.
16 371 627 435 691 499 755
1 327 583 391 647 455 711
2 330 586 394 650 458 714
3 333 589 397 653 461 717
4 336 592 400 656 464 720
5 339 595 403 659 467 723
6 342 598 406 662 470 726
7 345 601 409 665 473 729
8 348 604 412 668 476 732
9 351 607 415 671 479 735
10 354 610 418 674 482 738
11 357 613 421 677 485 741
12 360 616 424 680 488 744
13 363 619 427 683 491 747
14 366 622 430 686 494 750
15 369 625 433 689 497 753
Zone PID data No.
Sets the PID data No. to be used in
segments.
16 372 628 436 692 500 756
To Next Page
