3 - 55 3 - 55
MELSEC-Q
3 SPECIFICATIONS
(From previous page)
Write condition *1
Address
(Decimal (Hexadecimal))
CH1 CH2
Settings Range
Default
value
Always
Setting
mode
Disabled
346(15AH) 602(25AH)
Set value(SV) Input range 0 —
—
347(15BH) 603(25BH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
348(15CH) 604(25CH)
Segment 8
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
349(15DH) 605(25DH)
Set value(SV) Input range 0 —
—
350(15EH) 606(25EH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
351(15FH) 607(25FH)
Segment 9
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
352(160H) 608(260H)
Set value(SV) Input range 0 —
—
353(161H) 609(261H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
354(162H) 610(262H)
Segment
10
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
355(163H) 611(263 H)
Set value(SV) Input range 0 —
—
356(164H) 612(264H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
357(165H) 613(265 H)
Segment
11
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
358(166H) 614(266 H)
Set value(SV) Input range 0 —
—
359(167H) 615(267H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
360(168H) 616(268H)
Segment
12
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
361(169H) 617(269H)
Set value(SV) Input range 0 —
—
362(16AH) 618(26AH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
363(16BH) 619(26BH)
Segment
13
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
364(16CH) 620(26CH)
Set value(SV) Input range 0 —
—
365(16DH) 621(26DH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
366(16EH) 622(26EH)
Segment
14
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
367(16FH) 623(26FH)
Set value(SV) Input range 0 —
—
368(170H) 624(270H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
369(171H) 625(271H)
Segment
15
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
370(172H) 626(272H)
Set value(SV) Input range 0 —
—
371(173H) 627(273H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
372(174H) 628(274H)
Program pattern 1
Segment
16
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
(To next page)
