3 SPECIFICATIONS
(From previous page)
Write condition *1
Address
(Decimal (Hexadecimal))
CH1 CH2
Settings Range
Default
value
Always
Setting
mode
Disabled
384(180H) 640(280H)
Final segment 1 to 16 16 —
—
385(181H) 641(281H)
Pattern link 0 to 3 (0: No link) 0 —
—
386(182H) 642(282H)
Iteration 1 to 999 times, 1000: Endless 1 —
—
387(183H) 643(283H)
Output time of pattern end
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
388(184H) 644(284H)
Wait zone 0 to full-scale 0 —
—
389(185H) 645(285H)
Set value(SV) Input range 0 —
—
390(186H) 646(286H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
391(187H) 647(287H)
Segment 1
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
392(188H) 648(288H)
Set value(SV) Input range 0 —
—
393(189H) 649(289H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
394(18AH) 650(28AH)
Segment 2
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
395(18BH) 651(28BH)
Set value(SV) Input range 0 —
—
396(18CH) 652(28CH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
397(18DH) 653(28DH)
Segment 3
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
398(18EH) 654(28EH)
Set value(SV) Input range 0 —
—
399(18FH) 655(28FH)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
400(190H) 656(290H)
Segment 4
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
401(191H) 657(291H)
Set value(SV) Input range 0 —
—
402(192H) 658(292H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
403(193H) 659(293H)
Segment 5
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
404(194H) 660(294H)
Set value(SV) Input range 0 —
—
405(195H) 661(295H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
406(196H) 662(296H)
Segment 6
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
407(197H) 663(297H)
Set value(SV) Input range 0 —
—
408(198H) 664(298H)
Executing
time
0 to 30000 (
0.01s, 0.1s,
1s, 1min)
0 —
—
409(199H) 665(299H)
Program pattern 2
Segment 7
Zone PID
data No.
0 to 8 (0: Specifies zones
including current set value)
0 —
—
(To next page)
*1: Reading is always available regardless of the write conditions. The item of which write condition is set
to "Setting mode" is changeable on setting mode only. Note that changing items during the operation
mode causes a write data error. In addition, it is necessary to turn on the setting change command
(YnB) for changing the setting.
