Mitutoyo DP-1VA LOGGER User Manual

4
1 Outline
No. 99MAM029A
1.3
Names and Main Functions of Each Part
1.3.1 Names of Each Part
OPEN
EXT.P
Must use the following types of battery
for battery operation.
Alkaline battery LR6
AA Ni-MH battery
+ −
Mitutoyo Corporation
MADE IN JAPAN
Code No.
Model
Serial No.
Power
INPUT OUTPUT ADAPTER
IN OUT
USB micro connector
/B receptacle
( )
Back Side
Power LED
Tolerance judgment
LED
Printer paper cover
DC jack
(ADAPTER)
Output connector *
(OUTPUT)
Input connector
(INPUT)
* The output connector is also used as
an input connector of the KA Counter.
Foot switch connector (EXT.P)
Release lever
Battery box cover
Strap eyelet
Operation
key
For further details on the attaching method of
the strap, refer to
"1.1 Packing Content
Conrmation" on page 1.
