Mitutoyo DP-1VA LOGGER - Specifications; General Specifications

73
7Specications
No. 99MAM029A
7
Specications
In this chapter, general specications, calculation specications, connection with various
optional devices and options are explained.
7.1
GeneralSpecications
Items Description Note
Code No. 264-505
Data input
Digimatic, Digimatic 2, RS-232C input (for
KA Counter only)
Printing method Thermal Line Printer
Character specica-
tions
Total dot number: 384 dots/line
Dot size: 8 dots/mm
NORMAL font: 24 (H) x 16 (W) dots
LARGE font: 36 (H) x 24 (W) dots
Print speed 0.8 s/line (6.5 mm/s) When using AC adapter
Print line number
7,000 lines/roll (with LARGE font)
10,000 lines/roll (with NORMAL font)
Printer paper to be
used
High-durability thermal paper, width: 58 mm,
roll length: 48 m
In the case of long-
term storage or use
for ofcial documents,
the use of photocopies
is recommended.
Power supply
y 100-240 V 50/60 Hz AC adapter (6 V, 2 A)
y AA alkaline batteries (LR6) or nickel-met-
al-hydride (Ni-MH Size AA) x 4
Two power source
system
Dry batteries are not
included.
Battery life
About 10,000 lines (in case of use at 20 °C,
with 1,600 mA Ni-MH and print 1 time/5 s)
Reference value (bat-
tery life greatly varies
depending on the use
conditions)
Data processing
capacity
MODE0: 100,000 data entries
MODE1, 2: 9,999 data entries
MODE3: sample size 10 x subgroup 9,999 =
Total number of data entries 99,990
Tolerance judgment Possible to set 5 pairs
Logging of the
measurement data
(to store)
Max. 1,000 points
Timer input 0.25 s, 1 s, 5 s, 30 s, 1 min, 30 min, 60 min
Data Output
USB output
RS-232C output at TTL level
Tolerance judgment result output (-NG, GO, +NG)
Clock precision ±2 min max./month
Battery life of the
backup batteries
About 10 years Reference value
