2 Basic Operations
No. 99MAM029A
2
Basic Operations
The basic operation of the product will be explained as a series of the ow.
2.1
Setup
2.1.1 AC Adapter Connecting and Battery Cells Setting
A power supply through an AC adapter or batteries is required to power the product.
Connecting the AC adapter
Connect the power plug of the accessory AC adapter to an electrical outlet, and the DC
plug to the DC jack
(ADAPTER)
on the right side of the product.
Use only one of the following of our specied AC adapters. Use of an AC adapter not included in
the list below may result in poor print quality and shorten the printing life.
• Plug for Japan and North America (Parts No. 06AFZ950JA or 06AEG180JA)
• Plug for China (Parts No. 06AFZ950DC or 06AEG180DC)
• Plug for Europe (Parts No. 06AFZ950D or 06AEG180D)
• Plug for the UK (Parts No. 06AFZ950E or 06AEG180E)
• Plug for Korea (Parts No. 06AFZ950K)
DC jack
Tips
Insert the DC plug of the AC adapter securely all the way into the DC jack.
To Next Page
