Mitutoyo DP-1VA LOGGER User Manual

64
5 Function Settings
No. 99MAM029A
Setting
order
Setting items Setting/print contents
8 BACK FEED ON ♦, OFF
(displayed only when NORMAL is selected in PRINT SIZE)
9
POWER SAVE
SAVE: Power save, NORMAL: Standard ♦
10 PRT DENSITY
(Density of the print)
NORMAL ♦, DARK
11 BUZZER (Buzzer
sound)
On: Sound ♦, Off: No sound
12 TIME PRINT (Clock
function)
On: Use ♦, Off: Not use
13 DATE FORMAT
(Print format of the date)
YYYY/MM/DD ♦, MM/DD/YYYY, DD/MM/YYYY
14
DATE
For January 2, 2018:2018/1/2, JAN/2/2018, 2/JAN/2018
15
TIME
For 14:25 pm: 14:25
16 UNIT * AUTO can be selected only in DP-1 mode
AUTO♦ (Only mm units can be accepted), mm: millimeter,
inch: inch, no unit, g: gram, °C: temperature, t: ton, lb: pound,
N: newton, Nm: newton-meter, μm: micrometer, μin: microinch
17 LOG RESUME
(Log state setting at the
time of activation)
1: Log stop ♦, 2: Log start, 3: Assume the log state when the
power was turned off last time
18 OUT LOG
(Log output setting)
Log print:
1: Time/Measurement value ♦, 2: N number/Measurement value,
3: N number/Date/Time/Measurement value
Log USB output:
1: Time/Measurement value ♦, 2: Measurement value, 3: Date/
Time/Measurement value
19 INPUT AXIS (Data input
object axes setting)
* Set only in MP mode
XYZ ♦, X, Y, Z (multiple settings are possible)
20 CUL AXIS
(Calculation object axes
setting)
* Set only in MP mode
X ♦, Y, Z (only 1 axis can be set)
Tips
• When setting "PRINT SIZE" (print character font size) to "NORMAL", move to the "BACK FEED"
setting subsequently. Normally, use with this setting "ON".
• When this is set to "AUTO" in the "UNIT" setting, length units other than mm cannot be accept-
ed.
• If the setting other than "AUTO" is selected in the "UNIT" setting, the print is performed in the
unit set with this parameter regardless of the input data unit. In this case, the input data unit
information is ignored.
• If there is no data with the designated axis in the input data in "CUL AXIS" (Calculation object
axes setting), the error message is printed (example: if the input data is for the X axis, "NO CUL
AX" is printed). In this case, use with "WORK MODE" in Setting Order 3 set to "MODE0". The
statistical calculation is not performed but the data can be printed.
• MP mode can be used only for RS-232C output of our KA Counter. The proper operation is not
guaranteed if equipment other than the KA Counter is connected for use.
