How to read this document
z
To measure
Setup of this product and the setting of parameters (if necessary) are required in advance.
"1 Overview" (page 1) to "3.4 Overview of Parameter Setting" (page 28)
For basic operation, see
"4 Basic Operations" (page 31)
For applied operation, see
"4.7 CEL-Specic Parameter Setting" (page 37) in addition to the
above chapter.
z
When you do not know the appropriate operation while using this product
Look for the page with the desired operation in the table of contents.
z
Terms and denitions
y Internal counter (CEL): Four internal counters (CEL1–CEL4) which perform the origin setup, toler-
ance judgment, and peak detection for the input counter value.
y BANK: Switchable display unit. BANK1 displays CEL1 and CEL2, BANK2 displays CEL3 and
CEL4.
y UNIT: Six input circuits for various measurements.
Tips
For details about BANK, CEL, and UNIT, see "3.3.1 Internal Structure of the Counter" (page 22).
