Mitutoyo LGH Series User Manual

59
7Specications
No. 99MBC122A
7
Specications
7.1
BasicSpecications
Code No. 542-715 542-716
Model No. LGH-1010-B-EH LGH-1010C-B-EH
Minimum resolution *1 0.00001 mm (0.01 µm)/0.0001 mm (0.1 µm)
Measuring range 10 mm
Indication accuracy
(20 °C) *2
0.2 µm
Repeatability (2σ) *2 0.1 µm
Retrace error *2 0.1 µm
Maximum response speed
*2
Normal measurement: 700 mm/s
Peak detection: 120 mm/s
Stem diameter ø15 h6 (0/ -0.011)
Contact point
Carbide Sø3 (M2.5 x 0.45)/Part No. 901312
Measuring
force
Contact point
downwards
0.65 N or less Approx. 0.12 N
Contact point
horizontal
0.55 N or less Not available
Contact point
upwards
0.45 N or less Not available
Available counter EH Counter (dedicated to LGH-1010-B/Standard accessories)
Power supply/Power con-
sumption *2
Supplied AC adapter or DC +12 V–+24 V
Max. 8.4 W (Max. 700 mA)
For commercial power source, ensure at least 1 A power supply per unit.
Operating temperature/
humidity range
0 °C–40 °C/20 % –80 % RH (no condensation)
* Recommended operating temperature: 20 °C ± 1 °C
Storage temperature/hu-
midity range
-10 °C–+60 °C/20 % –80 % RH (no condensation)
Unit mass Gage head: Approx. 370 g (including the signal connection cable)
Counter: Approx. 900 g (excluding the AC adapter)
CE Marking
EMC Directive：EN 61326-1
Immunity test requirement：Clause 6.2 Table2
Emission limit：Class B
RoHS Directive：EN IEC 63000
*1 The setting can be changed using the counter.
*2 When using the supplied counter
