5 External Input/Output Function
No. 99MBC122A
5
External Input/Output Function
This product is equipped with the following interfaces that enable the connection of external
equipment.
Interface
Parameter setting
(No. 24)
Connectable equipment Functions
Digimatic
output
2 Digimatic Mini-Processor
(DP-1VA LOGGER)
y Printing the measurement
data, statistical calculation
results, etc.
USB 1 PC (for SENSORPAK) y Data output to a PC
RS-232C 0 PC, PLC y Data output to a PC, PLC
y Control from external sys-
tem
I/O connector - Equipment such as a switch
or control unit
y Data output to PLC
y External control of the
counter
Tips
PLC: programmable logic controller
5.1
Digimatic Output Function (for DP-1VA LOGGER)
You can print the measurement data by connecting to the Digimatic Mini-Processor (DP-1VA LOG-
GER), which is sold separately.To do this, connect the Digimatic cable to the RS_LINK connector
(OUT) of the counter.
Tips
• A maximum of 6 digits can be printed. When the counter displays the value in 7 or 8 digits, the last 6 digits
will be printed. For example, when "12.34567 mm", which has 7 digits, is output, it will be printed as "2.34567
mm".
• Set the DP-1VA LOGGER to compatible mode.
For details on the setting method and operations, see
"DP-1VA LOGGER Digimatic Mini-Processor
User's Manual".
• When an error occurs, an asterisk is printed.
• If you use an old model instead of the Digimatic Mini-Processor DP-1VA LOGGER, contact your dealer or
the nearest Mitutoyo sales o󰀩ce.
5.2
USB Communication Function
By installing SENSORPAK (Mitutoyo product) on a PC, you can load measurement data from the
counter to the PC by connecting the counter to the PC with a USB connecting cable (A-B type). A
USB connecting cable is not supplied. You must provide one.
