3.3.2 Details of Display Mode Selection (Parameter Number 06)
For this counter, Display mode can be selected by setting Parameter Number 06 as follows:
Set value Display mode
BANK1 BANK2
CEL1 CEL2 CEL3 CEL4
0 Two-coordinate
display
UNIT_A
(A-axis counter)
UNIT_B
(B-axis counter)
UNIT_A
(A-axis counter)
UNIT_B
(B-axis counter)
1 Calculation
display
UNIT_C
(A±B)
UNIT_A
(A-axis counter)
UNIT_C
(A±B)
UNIT_B
(B-axis counter)
2 Dual display UNIT_A
(A-axis counter)
UNIT_A
(A-axis counter)
UNIT_B
(B-axis counter)
UNIT_B
(B-axis counter)
3 Memory display UNIT_A
(A-axis counter)
UNIT_F
(Memory)
UNIT_B
(B-axis counter)
UNIT_F
(Memory)
4 Speed display UNIT_A
(A-axis counter)
UNIT_D
(A-axis speed)
UNIT_B
(B-axis counter)
UNIT_E
(B-axis speed)
5
(Default
value)
Optional
one-axis display
UNIT_A
(A-axis counter)
- - -
6 Optional
two-axis display
UNIT_A
(A-axis counter)
(Default value)
UNIT_B
(B-axis counter)
(Default value)
- -
7 Optional
four-axis display
UNIT_A
(A-axis counter)
(Default value)
UNIT_B
(B-axis counter)
(Default value)
UNIT_C
(A±B)
(Default value)
UNIT_A
(A-axis counter)
(Default value)
Tips
• The set values 0–4 of Parameter Number 06 do not allow the connection from UNIT to CEL to be modied.
• The set values 5–7 of Parameter Number 06 allow CEL to be connected to any UNIT.
• With the set value 0–4, CEL assigned to UNIT_B (B-axis counter), UNIT_C (A±B), or UNIT_E (B-axis speed)
cannot be used, showing "Error40".
For details about the parameter setting, see "3.1 Procedure for Setting Parameters" (page 17).

Display mode type
z
Two-coordinate display (set value: 0)
A set of two counters (CEL) of BANK1 and 2 is used to display the two coordinates.
BANK1 BANK2
Ach (upper display) CEL1 UNIT_A (A-axis counter) CEL3 UNIT_A (A-axis counter)
Bch (lower display) CEL2
Error 40
(UNIT_B (B-axis counter))
CEL4
Error 40
(UNIT_B (B-axis counter))
Tips
• CEL assigned to UNIT_B (B-axis counter) cannot be used, showing "Error40".
• The origin (preset) and tolerance can be set per BANK.
For details about BANK switchover, see "4.2 Switching the Displayed BANK" (page 31).
For details about the origin setting (preset), see
"4.4 Preset" (page 32).
For details about the tolerance setting, see
"4.6 Tolerance Value Setting" (page 34).
