3 Parameter Setting
No. 99MBC122A
z
Calculation display (set value: 1)
The Sum/Dierence calculation display cannot be used.
z
Dual display of current value/peak value (set value: 2)
The current and peak values of one gage are simultaneously displayed.
BANK1 BANK2
Ach (upper display) CEL1 UNIT_A (A-axis counter) CEL3
Error 40
(UNIT_B (B-axis count-
er))
Bch (lower display) CEL2 UNIT_A (A-axis counter) CEL4
Error 40
(UNIT_B (B-axis count-
er))
Tips
• CEL assigned to UNIT_B (B-axis counter) cannot be used, showing "Error40".
• The origin sets of Ach (upper display) and Bch (lower display) are independent.
z
Memory display (set value: 3)
The value of Ach (upper display) is saved in Bch (lower display).In addition to the most recently saved
data, the maximum and minimum values from past data can also be read out.The saved data are not
cleared even if the power switch is turned o.
BANK1 BANK2
Ach (upper display) CEL1 UNIT_A (A-axis counter) CEL3
Error 40
(UNIT_B (B-axis count-
er))
Bch (lower display) CEL2 UNIT_F (Memory) CEL4 UNIT_F (Memory)
Tips
• CEL assigned to UNIT_B (B-axis counter) cannot be used, showing "Error40".
• The memory unit is shared between BANK1 and BANK2.Used gages must have the same signal cycle
output.
• The B_HOLD signal from the I/O connector can be used for external control.
For details about the procedures for saving, reading out, and clearing memory, see "4.8 Register-
ing, Reading, and Clearing Memory" (page 39).
For details about input/output from the I/O connector, see
"5.5 I/O Connector Terminal Function"
(page 48).
