Mitutoyo LGH Series User Manual

27
3 Parameter Setting
No. 99MBC122A
3.3.3 CEL-Specic Parameters
This section describes the parameters that can be set per CEL.
No. Set value
Description/Set values
(The values in bold indicate initial values.)
40 Individual CEL display
selection
Selects UNIT (counting method) to be displayed for each CEL when Parame-
ter Number 06 is set to a value between 5–7.
Modifying the value of Parameter Number 40 clears the preset and tolerance
values.
0: UNIT_A (A-axis counter)
1: (Not available)
2: (Not available)
3: UNIT_D (A-axis speed)
4: (Not available)
5: UNIT_F (Memory)
41 Calculation with a
constant
Sets whether or not to multiply the internal counter value by one of the prede-
termined values or an arbitrary value.The internal counter value multiplied by
the specied constant value is displayed as the measurement result.
0: None
1: 1/2 times
2: 2 times
3: 10 times
4: Arbitrary value
42 Lowest-order digit
blank
Hides the lowest-order digit.
However, the lowest-order digit will be included in RS-232C output and in
printouts.
0: Display all digits
1: The lowest-order digit is blank
Tips
• For this product, Parameter Number 40 cannot be set to 1, 2, or 4.
• When Parameter Number 41 is set to 4 (arbitrary value), accuracy guarantee is disabled.
• For details about the CEL-specic parameter setting, see
"4.7.1 Procedure for Setting CEL-Specic Pa-
rameters" (page 37).
