3 Parameter Setting
No. 99MBC122A
z
Speed display (set value: 4)
Displays the moving speed of the spindle simply.The display unit of speed is mm/s. In addition to the
current speed, it displays the maximum speed when the maximum value (MAX) is selected in Peak
mode.
BANK1 BANK2
Ach (upper display) CEL1 UNIT_A (A-axis counter) CEL3
Error 40
(UNIT_B (B-axis count-
er))
Bch (lower display) CEL2 UNIT_D (A-axis speed) CEL4
Error 40
(UNIT_E (B-axis speed))
Tips
• CEL assigned to UNIT_B (B-axis counter) or UNIT_E (B-axis speed) cannot be used, showing "Error40".
• The display of the last 1 to 3 digits may be xed depending on the sampling cycle.
• The maximum speed in the reverse direction is displayed when the minimum value (MIN) is selected in Peak
mode.
• The speed display is simplied and may not be correct.
z
Optional one-axis display (set value 5), optional two-axis display (set value 6), optional
four-axis display (set value 7)
Select the number of CELs to use from 1, 2, and 4, and connect each CEL to any UNIT.You can con-
gure any measurement mode other than the set values 0–4 of Parameter Number 06.Set Parameter
Number 06 to a value between 5–7, and connect UNIT according to the CEL-specic parameter.
Tips
UNIT_B (B-axis counter), UNIT_C (A±B), and UNIT_E (B-axis speed) cannot be used.If they are connected to
CEL, they show "Error40".
For details about the CEL-specic parameters, see "3.3.3 CEL-Specic Parameters" (page 27).
