1 Overview
No. 99MBC122A
1.4
For Accurate Measurement
1.4.1 Precautions for Measurement
• For accurate measurement, turn on the power, warm up the product for 30 minutes or more and
start measurement.
• Be sure to perform adequate thermal stabilization of this product and the workpiece.
• Wipe o the tip of the contact point and the measuring surface to remove dust or dirt before mea-
suring.
• This product does not guarantee accuracy in a range of 0.2 mm from the bottom dead center
(spindle in the state protruded most).Lift the spindle 0.2 mm or higher from the bottom dead center
when performing Zero setting and preset setting.
A steep level dierence may cause a miscount or error. Fully consider
the measuring method.
1.4.2 Eect of Temperature Environment on Accuracy
The prescribed accuracy may not be obtained when the product is used at a temperature other than
20 °C. Pay particular attention to the temperature environment.
Workpiece
To Next Page
