Mitutoyo LGH Series User Manual

62
7Specications
No. 99MBC122A
7.3
Option
Code No./
Part No.
Name Dimensional
drawing
971750 LGH measurement stand page 62
971751 Holder A page 63
971752 Holder B page 64
971753 Release for LGH page 64
02ADB440 I/O output connector (with cover) -
02ADD950 RS-LINK/Digimatic connection cable (0.5 m) -
936937 RS-LINK/Digimatic connection cable (1 m) -
965014 RS-LINK/Digimatic connection cable (2 m) -
02NGB070 SENSORPAK (software for loading data to PC) -
21HZA137 I/O CABLE SET FOR SENSORPAK (RS-232C cable) -
264-505 Digimatic Mini-Processor DP-1VA LOGGER -
- Contact points for dial indicator
For details, see the General Catalog.
-

LGH measurement stand
y External dimensions: 250 (W) x 300 (D) x 365 (H) mm
y Mass: 23 kg
y Maximum measuring range: 0 mm–137 mm
Gage
mounting
hole
Unit: mm
