64
7Specications
No. 99MBC122A
Holder B
Unit: mm
M4 Hexagon socket
head cap screw
(For xing the gage)
Mounting reference surface
Gage mounting hole
2-M5 E󰀨ective depth: 10
Holder
mounting
surface
Release for LGH
Total length: 504 mm
Return speed adjustment knob
