Outdoor Station
Allowed wall thickness for
cavity installation:
min. 7 mm/0.28 in,
max. 27 mm/1.06 in
7 mm/0.28 in to
27 mm/1.06 in
131 mm/5.16 in
50 mm/1.97 in
97 mm/3.82 in
318 mm/12.52 in (double housing: 218 mm/8.58 in, single housing: 129 mm/5.08 in)
333 mm/13.11 in (2double housing: 233 mm/9.17 in, single housing: 143 mm/5.63 in)
69 mm/2.72 in
