Installing the T26 Modules
7. Put the cover plate back on.
8. First of all, insert the right side of the module into the frame. Then press rmly on
the le side, until the module audibly clicks into place.
Control click: If you do not hear a click, this means that the module is not properly locked
into place. In this case, repeat the last steps, making sure that no cable or foreign object in
the housing is preventing the module from properly clicking into place.
Caution
Do not activate the the protection lock until you have checked the wiring (see
Section 2.8.1). Also test the functionality of the the protection (see Section 2.4.7,
«Removing, Exchanging and Modifying Modules»).
Only press rmly on the
edge of the access mod-
ule (not in the middle)
Click
Cindy Jones
Thomas Jones
The Jones Family
Dr. Jones, MD
Click
