Fieldsontherst
setting block
Description
Enable Port Forwarding Check this item to enable the port-forwarding feature.
Protocol There are 3 options available: TCP, UDP and Both.
Enable Check this item to enable this entry.
Local IP Address IP address of your local server that will be accessed by
Internet.
Port The destination port number that is made open for this
application on the LAN-side.
Remote IP Address The source IP address from which the incoming trafc is
allowed. Leave blank for all.
External Port The destination port number that is made open for this
application on the WAN-side
Interface Select the WAN interface on which the port-forwarding
rule is to be applied.
Function Button Description
Apply Changes Click to change the setting of default actions to the conguration.
Delete Selected Delete the selected port forwarding rules from the forwarding
table. You can click the checkbox at the Select column to select
the forwarding rule.
Delete All Delete all forwarding rules from the forwarding table.
10.0.0.33
Congure Port Forwarding setting successfully!•
From the left-hand • Adminmenu, click on Commit/Reboot. The following page
is displayed:
Click on • OK.
